Controlled RF testing with real-world relevance....

RF Testing

Blending acoustical engineering expertise with advanced measurement technology, we deliver specialized RF Wall Testing that reveals how materials and assemblies impact radio frequency performance. Our team analyzes signal attenuation, interference patterns, and shielding effectiveness to help architects, engineers, and facility managers design spaces that achieve both acoustic precision and optimal RF control. We follow IEEE 299 testing standards to measure the effectiveness of electromagnetic shielding and enclosures—ensuring your project is compliant, defensible, and built to the highest standards.

Whether the goal is securing sensitive communications, improving wireless coverage, or meeting strict compliance requirements, we provide the data and insight needed to make informed, high-performance design decisions—ensuring every wall works as hard as the space it defines.

RF Testing Specs

24’ x 24’ x 15’

Testing Area – 14’ x 14’ x 10’

Parameters we can test against listed below

Magnetic FieldElectric FieldPlane WaveMicrowave
10 KHz - 30 dB10 KHz - 100 dB50 MHz - 100 dB2 GHZ - 80 dB
100 KHz - 50 dB100 KHz - 100 dB100 MHz - 80 dB4 GHZ - 80 dB
1 MHz - 60 dB1 MHz - 100 dB400 MHz - 95 dB6 GHZ - 80 dB
10 MHz - 80 dB10 MHz - 100 dB1000 MHz - 90 dB10 GHZ - 80 dB
30 MHz - 90 dB300 MHz - 100 dB12 GHZ - 70 dB
18 GHZ - 55 dB
Magnetic FieldElectric FieldPlane WaveMicrowave
10 KHz - 30 dB10 KHz - 100 dB50 MHz - 100 dB2 GHZ - 80 dB
100 KHz - 50 dB100 KHz - 100 dB100 MHz - 80 dB4 GHZ - 80 dB
1 MHz - 60 dB1 MHz - 100 dB400 MHz - 95 dB6 GHZ - 80 dB
10 MHz - 80 dB10 MHz - 100 dB1000 MHz - 90 dB10 GHZ - 80 dB
30 MHz - 90 dB300 MHz - 100 dB12 GHZ - 70 dB
18 GHZ - 55 dB
